Arduino Uno LCD TFT Shield — 40-Pin 8-Bit Interface

Upgrade your Arduino projects with the 40-Pin 8-Bit TFT LCD Shield for Arduino Uno. Designed for high-speed parallel data transfer, this shield supports a wide range of TFT LCD panels and is perfect for projects that demand fast display refresh rates and rich graphical output — all with a simple plug-and-play setup.

Key Features

• 40-pin connector supporting standard 8-bit parallel TFT LCD panels
• 8-bit parallel interface for high-speed data transfer and smooth display rendering
• Plug-in shield design — fits directly onto Arduino Uno / Mega headers
• Wide LCD compatibility — supports popular TFT panels with ILI9341, ILI9325, HX8347, and similar driver ICs
• Onboard SD card slot for reading images, icons, and data from microSD cards
• Resistive touch support (when used with touch-enabled LCD panels)
• Compatible with MCUFRIEND_kbv and Adafruit GFX libraries
• Operating Voltage: 5V via Arduino headers

Specifications

• Interface: 8-bit parallel (40-pin FPC connector)
• Compatible LCD Drivers: ILI9341, ILI9325, HX8347, R61505, and more
• SD Card: MicroSD slot included
• Touch: Resistive (LCD panel dependent)
• Supply Voltage: 5V
• Form Factor: Arduino Uno / Mega shield

What's in the Box

• 1x 40-Pin 8-Bit TFT LCD Shield for Arduino Uno

Ideal For

• Connecting large-format or custom TFT LCD panels to Arduino
• High-speed graphical display applications
• DIY HMI (Human Machine Interface) panels
• Data dashboards, meters, and instrument displays
• Prototyping with various TFT LCD screen sizes and drivers

If you need a versatile, high-speed display shield that works with a broad range of 40-pin TFT LCDs, this is your ideal Arduino companion.
